Mafell cross-cutting saw KSS 80 Ec / 370 - 918501
Description
Description
MAFELL's cross-cut saws combine power and precision with user-friendliness and ergonomics. These features merge into a unique system.
The saw is automatically retracted to its starting position after the cut and offers a maximum cutting length of 370mm at full cutting depth.
Concentrated power and high torque have a name: CUprex, the high-performance motor with performance-optimized digital electronics and newly developed control technology. The speed can be continuously adjusted to suit different materials and applications.
There is no longer any need to unscrew the splitting wedge - the FLIPPKEIL offers you optimal user comfort and safety when plunging.
AREA OF APPLICATION
- Cross cuts with guide device
- Longitudinal and cross-sectional sections
- Plunge and cutouts
- Material use e.g.: solid wood, panel materials, insulation, doors, worktops, interior fittings and renovations
ADVANTAGES
- The cutting depth can be adjusted and locked with just one hand movement.
- The rubberized underside holds the crosscut saw securely on the material and protects the workpiece surface from damage.
- The quick-release fastener allows the machine to be separated from the guide system with just one hand. This allows it to be used as a standalone circular saw with all the functions of the MAFELL KSP series.
SCOPE OF DELIVERY
- 1 HM saw blade 237 x 1.8/2.5 x 30 mm, 12 teeth, WZ, for longitudinal cuts in wood; Order No. 092590
- 1 parallel stop K 85-PA; Order No. 205323
- 1 suction nozzle; Order No. 205290
- 1 hexagon wrench 5 mm; Order No. 093034
- 1 guide device L, max. cutting length 370 mm; Order No. 208171
- 1 connection cable 4 m; Order No. 087888
TECHNICAL DATA
| Cutting depth with rail at 0° | 0 - 82 mm |
| Cutting depth with rail at 45° | 0 - 55.5 mm |
| Cutting depth without rail at 0° | 0 - 88 mm |
| Cutting depth at 60° | 0 - 38.5 mm |
| Angle cuts | -60 - +50 ° |
| Swivel range | 0 - 60 ° |
| Nominal idle speed | 2250-4400 rpm |
| Nominal power | 2300 W |
| Weight with rail | 8.3 kg |
| Universal motor | 230 V / 50 Hz |
