Bessey ceiling and assembly support with pump handle (2070-3700mm) - STE370

Extremely secure hold

The support guarantees a reliably secure hold:

• Thanks to its extremely stable construction, it can support loads of up to 200 kg – depending on the corresponding support size – at maximum extension length, thanks to rubberized PVC contact surfaces at the top and bottom, and thanks to the integrated anti-slip feature in the handle.

Versatile

It allows for the positioning and holding of a wide variety of materials:

• With a stable steel tube construction, available in three sizes – telescopically extendable up to 3.70 m thanks to 9 x 7 cm support plates with a swivel range of -45° to +45°

Precise and quick to handle

The support can be precisely adjusted to the requirements and safely released:

• The clamping mechanism is achieved in three steps: To pre-adjust the ceiling support, the release button is pressed and the telescopic inner tube is extended to the desired length. Fine adjustment is made by pressing the pump lever until the support's base plate rests against the workpiece. Then, turn the handle clockwise until the desired holding force is reached (observe the maximum load capacity). The clamping mechanism is released in two steps: First, turn the ceiling support counterclockwise. As soon as there is no longer any holding force, press the release button to retract the inner tube.

Product details

• Maximum load capacity of 350 kg with the telescopic pole fully retracted.
• Extremely stable construction thanks to heavy-duty steel tubes and non-slip PVC contact surfaces
• One-handed operation thanks to the 2-component plastic handle with pump mechanism
• Quick-release button for fast extension and retraction of the telescopic pole
• Adjustable holding force by turning the support on the handle
• Suitable for use even on slopes thanks to continuously adjustable contact surfaces from -45° to +45°

Technical data

Adjustment range 2070-3700 mm
Maximum load at maximum extension length: 65 kg
Maximum load capacity at maximum extension length: 350 kg
Weight 4.50 kg per piece
